1、Inner tank size：W700*H1300*D900mm；

2、Dimension：W1600*H2170*D1060mm；

3、Temperature range：Indoor temperature'20℃-250℃；

4、Fluctuation：≤±1℃；

5、Temperature uniformity：≤±3℃(Under constant temperature, no load test)；

6、Heating rate：≥8℃/min；

7、the Enclosure temperature: equipment within 250 ℃, the enclosure temperature is not higher than room temperature ' 10 ℃, with the exception of door around the joint.

8、Circulating air mode: horizontal air transport;

9、Power supply: three-phase five-wire system, 380V, 50HZ

10、Gross power：15KW；

11、Total weight of equipment: 400kg.

ⅡConstructional features of Drying oven on One hundred grade

1、Enclosure material：made of 2.0mm thick 304 stainless steel plate; ；

2、Interior material: made of 1.5mm thick mirror plate of SUS316L stainless steel ;

3、Frame: the oven body is made of 50*50*3mm Angle iron to maintain the bearing strength of each internal and external surface of the oven, and keep the heat expansion and cold shrinkage coefficient to prevent the oven body from deformation.

4、Thermal insulation material: 100K rock wool of encrypted aluminum silicate  with characteristics of non-combustible and strong heat insulation, with thickness of 150mm;

5、Sealing material: the sealing strip is made of transparent or white  silica gel of medical grade, which can withstand temperature without deformation. The door and the inner tank are in double-layer sealed to enhance the sealing effect.

6、Ventilation device: the upper part of the enclosure is provided with air inlet and air outlet;Φ 110 mm diameter, adjustable air flow, make the furnace temperature is uniform in the air inlet is equipped with a detachable filter, used for the oven ventilation, to ensure that the housing internal cleanliness, and longer service life and high efficiency filter inside.

7、High efficiency filter: the internal 100-grade clean filter adopts high-temperature resistance and high efficiency filter with separator design. The corrugated partition can accurately keep the spacing between folds.Under the minimum resistance, the filter material is utilized to the maximum extent. The filter material is folded by 180 folds on both sides, and there are two indentations when the filter material is bent.Making it open the fillet cartridge folds at the end of the partition, the fillet cartridge folds to prevent damage to the filter material.

8、tray: made of SUS316L stainless steel Φ 6 mm round steel points, 7 layers;Upper SUS316L stainless steel face punching plate;

9、Door: single door,two pieces reinforced  hinge  of chrome plated are installed on the right side to prevent door droop, and one piece square steel lock of chrome plated in explosion-proof  is installed on the left.Strong pretension, easy to operate.

10、Moving casters and cups: the bottom of the enclosure body is installed with the forma wheel that meets the load bearing, which facilitates the movement and fixation of the oven.

1、Eight-channel paperless recorder;

2、Time control:  time controller of LED digital display can be used to set the maximum time to 99 hours, and the unit can be arbitrarily switched to hours, minutes and seconds.

3、Control of heating tube: control each group of heating tube by SSR solid relay;
4、Temperature sensor: Omron in 3-meter standard, k-type thermocouple;

5、Others: all the control appliances are under the schneider brand.

1、Automatic constant temperature: the thermostat can calculate the output power automatically with PID according to the temperature value set by the user. The closer the temperature is to the set value,the smaller the output power will be.

2、Timing function: the timing is divided into two levels (manual/automatic) : start timing immediately when manual is selected;The time will start when the temperature must reach the set temperature value.Sound and light alarm and stop automatically when time is reached.

3、Over-temperature alarm: when the actual detection temperature exceeds the setting value of the over-temperature protection thermostat, automatically cut off the heating power, playing function of dualprotection function;

4、Audible and visual alarm: alarm lamp with buzzer;

5、Ground protection: safety ground protection of structural components;

6、Lack of phase-phase sequence protection of power: equipped with phase-sequence protector;

1、Environment temperature：-5℃-40℃；

2、Relative humidity：≤85%RH

3、Power supply：AC380V±10%，50Hz；
