Inner size：W2600*D1200*H300mm（The door height 180mm），independent inner tanks in 4 layers, independent temperature control

FDimension：W3000（Do not contain cylinder）*H1740*D1920mm（Contains no door）

Temperature range：Indoor temperature~250℃（Normal use）

Heating rate：Heat up to250℃ ≈20min

Temperature uniformity：±1.5%(no load)

Protection device:Device of timing alarm power cut off, over-temperature power cut off,breaker of leakage protection circuit,protection of motor overload, the chain is equipped with anti-card dead and alarm device.

Adopt intelligent temperature controller, PID automatic calculation, LED display and SSR solid relay output, which can precisely control the accuracy of temperature. The inner liner material is made of mirror 304# stainless steel plate. The argon arc welding can prevent dust from the machine.The outer is drying with a 2.0mm high temperature powder coat

Double overtemperature protection, more reliable safety;

Fast heating time, accurate temperature stability

Domestic first-class thermal insulation, thermal insulation technology, seal effect is remarkable

Low shell temperature has little effect on indoor environment temperature

Energy and power saving, strong safety performance

Gross power：52KW(380V 50HZ)。
