2、Dimension（约around）：W2760*H1990*D1640mm(No back motor)；

3、Temperature range：Indoor temperature-300℃ adjustable（The precision requirement150℃±1.5%，200-250℃±2%）；

4、Temperature fluctuation：≤±1℃；

5、Temperature uniformity：≤±3℃(no load)；

6、Heating rate：≤8℃/min；

7、the shell temperature: shell temperature is not higher than room temperature ' 15 ℃, around the door, except the seam.No burning at the highest temperature; 8、Circulating air mode: a large number of forced air circulation in horizontal circulation;

9、 Power supply: three-phase five-wire system, 380V, 50HZ;

10、Gross power：52KW；

11、Shell material: made by bending and welding of 2mm thick cold steel plate (with best strength, plasticity and welding comprehensive performance);

12、Guide rail: there is a guide rail for the trolley in the chamber body, and a limit is added to prevent the trolley from collapsing or hitting the back plate;

13、Explosion-proof door: the chamber body is equipped with an explosion-proof door at the top. The size is 360*280mm.

1、Air motor: Taiwan edeley 1.5kw air motor, set on the back of the oven;

2、Wind wheel: 14-inch multi-wing wind wheel;

3、Heating pipe: adopt stainless u-type heating pipe with radiator fin, which can make the temperature of heating pipe evenly distributed;

4、Air heating method: air is pumped from the air inlet of the oven to the air groove of the heating pipe. Air is circulated in the oven after being heated, and the exhaust gas is discharged from the exhaust port.
5、Time control: LED digital display time controller can be used to set the maximum time to 99 hours, and the unit can be arbitrarily switched to hours, minutes and seconds.

6、Control chamber: add three color indicator light on the control panel.

1、Over-temperature alarm: when the actual detection temperature exceeds the setting value of the over-temperature protection thermostat, automatically cut off the heating power and double protection function;

2、Audible and visual alarm: alarm lamp with buzzer;

3、Earthing protection: safety earthing protection of structural components;

4、Phase-missing and phase-sequence protection of power supply: reserve power connection chamber for protection;

5、Power junction box: reserve power connection box and protect it;

1、Enviroment temperature：-5℃-40℃；

2、Relative humidity：85%RH；

3、Power supply：AC380V±10%，50Hz。
